Specs
Peak Power - 64.4kVA
Continuous Output - 22.0kVA
Voltage - 230V @ 50Hz
Speed - 1500rpm
Engine - Kohler KDI 2504-M
Fuel - Diesel
Sound - 49 dB(A) @ 7m
Weight - 520kg
LxWxH - 1224x631x828
Includes
Sound Capsule
Remote Panel & Harness
Ext Anti-Vibe Mounts
Tool Kit
Manual
Superior Warranty
5 year warranty exclusive to leisure customers of Advance Yacht*
* Full details available on request
Powered By Kohler
The Paguro 22 EK is the latest in the range of 1500rpm generators from VTE. Based on their tried and trusted design that has been in successful production for many years, the Paguro 22 EK uses the new Kohler KDI2504-M fresh water-cooled engine with common rail direct injection technology meeting Tier 4 Final/ARB, Stage IIIB emissions compliance. The popularity of the Kohler & Paguro brands around the globe ensures that wherever you are in the world, you won’t be far away from spares and servicing support, giving you the freedom to cruise with peace of mind.
Installation Kits
We also supply comprehensive installation kits, put together using the same high quality parts we use in our professional marine installations. They include the known parts necessary to complete an installation, without you or your installer having to spend time sourcing additional parts. Each system group of parts is individually packed and labelled to make it easy; just open the box and begin!
How Will You Install Your System?
Whether you prefer a hands-off professional installation or plan to manage the fit-out yourself, we are here to support you every step of the way.
Approved Installation Partners: We work with a trusted network of professional marine engineers across the UK, Channel Islands, and Gibraltar. Visit our Approved Dealers & Installers page to find a installer near you.
Self-Installation & Independent Engineers: Tackling the project yourself or using your preferred engineer? You are never on your own. Our dedicated in-house technical team is just a phone call or email away, ready to provide expert advice and troubleshooting support during your installation and well beyond.
The Paguro Difference
Powerful
Paguro 22 EK is the ideal for supplying a combination of equipment such as multiple air conditioning units, a large watermaker and more.
Reliable Power
The combination of AVR regulated oversized watercooled brushless windings and a Kohler (Lombardini) engine will give you the power you need and the peace of mind you want.
Independence
With a Paguro 22 EK on board you can enjoy the full potential of your yacht. With a power greater than having shore power on board, you’ll have the freedom to explore in comfort and safety.
Peace & Quiet
Designed by one of the pioneers of encapsulated generator technology, the Paguro 22 EK is cocooned in a 4- stage soundproof capsule, keeping noise as low as possible. Two sets of anti-vibration feet ensure that noise transmitted by vibration is kept to a minimum, resulting in a smooth running and very quiet generator.
Simple Ownership
Easy to Operate
Your Paguro comes complete with an easy to read remote control panel with power monitor and 15m cable.
Volpi Tecno Energia
Manufactured by Volpi Tecno Energia, the Paguro brand is one of the longest established compact marine generators and is a well known firm favourite around the world. VTE focus on producing quiet, compact marine diesel generators that are durable in the marine environment and are easy to operate and maintain. Paguro generators are manufactured using proven techniques and high grade materials to ensure a long life in the marine environment. The factory is located in Udine in northeast Italy near Trieste, home to the Barcolana Sail Race, a spectacular annual race that is the largest sailing event in Europe.
Global Support
With distributors located in 74 countries world-wide, Paguro generators offer industry leading global support
UK Support
Our team here at Advance Yacht Systems have built a comprehensive knowledge base covering all aspects of the Paguro generator range, enabling us to deliver unrivalled technical support to our customers. Our commitment to providing industry leading support is backed up by us being voted British Marine Electrical & Electronics Dealer of the Year by our customers.
We also offer the largest range of generator spares of any UK marine generator distributor, available to buy online for delivery to over 50 countries worldwide.
