The YPOWER+ range is the 6th generation of HF chargers developed by CRISTEC. Features include automatic sensing and distribution of 100% of available charging to any one bank or a combination of up to 4 banks. The CRISTEC YPOWER+ chargers accept a wide input power supply range, enabling you to connect to shore power in marinas around the world.
Cristec YPOWER+ 12-70
£724.00 Excl. VAT
Sale price
£724.00 Excl. VAT
Regular price
Skip to product information
Cristec YPOWER+ 12-70
131-0108-PLUS
£724.00 Excl. VAT
Sale price
£724.00 Excl. VAT
Regular price
1 in stock
Pickup available at Advance Yacht Systems - Romsey
Usually ready in 1 hour
The Cristec YPOWER+ 12-70 battery charger features high quality power electronics for optimum performance at high temperatures and for silent operation - no fans are required.
4 Independent Outputs
Fully-automatic 5-stage charging
Simple dip-switch programming to select the right charge curve for your battery type - Lithium, LiFePO4, Sealed Lead, Gel, AGM, Wet Lead
Ignition Protected - ISO8846 Compliant
CAN-BUS & Bluetooth App Control
PFC (power factor correction) and modern HF technology to increase performance and efficiency
Sheet 01 — Specification
Specifications
| Voltage | 12V |
|---|---|
| Charge Output (A) | 70A |
| No. of Outputs | 4 |
| Fanless | Yes |
| CAN-BUS | Yes |
Sheet 02 — At A Glance
Key Features
Fanless
Passively cooled resulting in silent operation and an optimized lifespan
App Control
Equipped with Bluetooth Low Energy (BLE) for app control
4 Independent Outputs
Features 4 independent outputs, including one dedicated to the engine battery
High Performance
Rated charge up to +40 degrees C with no de-rate. ISO8846 compliance – protection against ignition of flammable gases
Sheet 03 — Technology
Cristec YPOWER+ 12-70
Latest Technology
Optimum Charging
CRISTEC chargers are designed to work with all battery types. Their simple dip-switch programming allows you to select the right charge curves to suit your batteries; gel, AGM, flooded, Calcium-Lead, Lithium… This ensures your batteries receive the correct charge and are kept in excellent condition.
Paralleling
YPOWER+ chargers can be installed in parallel and work together to increase output. For example, if you have an existing YPOWER+ 12-40 charger and want to increase your charging capability to 60A, simply add a YPOWER+ 12-20. Up to 4 YPOWER+ chargers can be banked together.
5-Stage Charging
Boost: charges batteries to 80% of full charge. Absorption: slowly completes remaining charge to 100%. Floating: maintains battery charge. Automatic refresh: prevents sulphation and revitalizes batteries, selectable by internal switch. Reboost: new automatic Boost phase if battery demand needs it.
Sheet 04 — The Manufacturer
Cristec
CRISTEC have specialised in power conversion since 1983 and with over 100,000 units in use around the world, they are the market leader in modern high performance, switch mode battery chargers. Manufactured in Quimper, Brittany, CRISTEC have an extensive R & D department backed up by a specialist testing facility to ensure product ranges meet demanding technical specifications. CRISTEC chargers are fitted as standard equipment to Jeanneau, Beneteau and Bavaria yachts amongst others. They are also used in many military and vehicle applications due to their durability and reliability in tough environments. With a distribution network spanning over 50 countries, you can be assured of quality service around the globe.
